5000吨无动力油驳出售

船舶编号:13483

#

阅读量

286 次

1 / 0

详细参数

船号 32-498609

微信小程序

微信扫描下方二维码,直接在微信中打开小程序查看此 船舶ID: 13483 信息详情:


微信小程序码

免责声明

本网页所展示的有关信息/图片/参数等由商家自行发布,真实性、准确性和合法性商家自行负责,本平台(本网站)仅提供展示服务,请谨慎交易,因交易而产生的法律关系及法律纠纷由您自行协商解决,本平台(本网站)对此不承担任何责任。

5000吨无动力油驳出售

船舶编号 : 13483

出售价格:

¥ 面议

所属船舶分类:

多用途船


5600CBM OIL BARGE NON PROPELLING FOR PALM OIL AND FUEL OIL(3 units)
Built: 2013, Jiang Su, China
Class: B.V
Location: China
Capacity: abt. 5600m3 (0.9t/m3 Cargo Density)
Cargo pump: 400m3/h x 2 sets
Genset: 30KW, Weichai
Principal Particulars
Length: 76.25 M (250Ft)
Beam: 22.32 M ( 73Ft)
Depth: 6.10 M ( 20Ft)
Draft: 4.35M
Deadweight: abt. 5000t
Engine room is located aft on main deck. Following equipments to be located in engine room:
(1) Two oil cargo pumps : Capacity:350m3/h, head:40m, 1450rpm shaft power: 80KW(350cst)
(2) Two diesel engines: to drive the oil cargo pumps, capacity: 100Kw, 1500rpm.
(3) Two clutch and transmission box: connect cargo pump and diesel engine.
(4) One tank stripping pump Capacity: 16.7m3/h head: 40m, to be driven by diesel engine.
(5) Two generators: capacity: 30Kw. AC380V,50Hz, IP22
(6) One GS / fire pump: capacity: 35 m3/h, head:42m, self priming, drive by electric motor
(7) One bilge pump: capacity: 35 m3/h, head:42m, self priming, drive by electric motor
(8) Oily water separator (type approved) located in engine.
(9) Two axial-flows fan, to supply air to the engine room and pump room space.
(10) Two fuel oil day tanks: capacity: 10m3
(11) One electrical panel: including AC380v, AC220v and DC24v
(12)Coiled: nil
Delivery: Jiangsu,China
